| Designation | KA035XPO |
| d | 88.9 mm |
| D | 101.6 mm |
| B | 6.35 mm |
| Bearing Type | Ball |
| Load Direction | Four-point contact |
| Seal Type | Open |
| Ring material | GCR15 bearing steel |
| Ball material | GCR15 bearing steel |
| Cage material | Brass |
| Precision level | ABEC-1 |
| weight | 0.08 kg |
| Designation | Dimensions（mm) | Loading Capacity（N) | Mass | |||||
| d | D | H | Cor | Cr | Coa | Ca | Kg | |
| KA020XP0 | 50.8 | 63.5 | 6.35 | 1650 | 1420 | 7600 | 3510 | 0.048 |
| KA025XP0 | 63.5 | 76.2 | 6.35 | 3690 | 1600 | 9290 | 4050 | 0.059 |
| KA030XP0 | 76.2 | 88.9 | 6.35 | 4400 | 1820 | 10980 | 4490 | 0.068 |
| KA035XP0 | 88.9 | 101.6 | 6.35 | 5070 | 2000 | 12670 | 4930 | 0.082 |
| KA040XP0 | 101.6 | 114.3 | 6.35 | 5730 | 2130 | 14310 | 5380 | 0.09 |
| KA042XP0 | 107.95 | 120.65 | 6.35 | 6090 | 2220 | 15160 | 5600 | 0.095 |
| KA045XP0 | 114.3 | 127 | 6.35 | 6400 | 2310 | 16000 | 5820 | 0.1 |
| KA047XP0 | 120.65 | 133.35 | 6.35 | 6760 | 2400 | 16850 | 6000 | 0.104 |
| KA050XP0 | 127 | 139.7 | 6.35 | 7070 | 2490 | 17690 | 6220 | 0.109 |
| KA055XP0 | 139.7 | 152.4 | 6.35 | 7780 | 2620 | 19380 | 6580 | 0.118 |
| KA060XP0 | 152.4 | 165.1 | 6.35 | 8450 | 2800 | 21070 | 6980 | 0.13 |
| KA065XP0 | 165.1 | 177.8 | 6.35 | 9110 | 2930 | 22760 | 7330 | 0.14 |
| KA070XP0 | 177.8 | 190.5 | 6.35 | 9780 | 3070 | 24450 | 7690 | 0.15 |
| KA075XP0 | 190.5 | 203.2 | 6.35 | 10450 | 3200 | 26140 | 8050 | 0.16 |
| KA080XP0 | 203.2 | 215.9 | 6.35 | 11110 | 3330 | 27830 | 8400 | 0.172 |
| KA090XP0 | 228.6 | 241.3 | 6.35 | 12490 | 3600 | 31200 | 9070 | 0.2 |
| KA100XP0 | 254 | 266.7 | 6.35 | 13820 | 3870 | 34580 | 9690 | 0.227 |
| KA110XP0 | 279.4 | 292.1 | 6.35 | 15160 | 4130 | 37960 | 10310 | 0.236 |
| KA120XP0 | 304.8 | 317.5 | 6.35 | 16540 | 4360 | 41340 | 10890 | 0.254 |
